Fiber Laser Source

Fiber Laser Source

    Description

    Pulsed fiber laser source is designed for high-speed and efficient laser marking system. Compared to traditional laser machines, pulse laser can increase transforming efficiency per watt of pump light. It’s at least ten times faster than traditional one. Automated pattern of low consumption fits the operation in laboratories or outside. The delicate machine can be placed independently. It can be used at any time and can be connected to the user’s device directly.

Specifications:

Pulse fiber laser 20W
The output central wavelength (nm) 1060~ 1085
Polarization Random
High reflection (With optical isolator) Yes
Average power (W) 20 (30W to 15kW optional)
Single pulse energy (mJ)@20kHz 1
Beam quality (M2) <1.8
Spot diameter (mm) 6~8
Impulse width (ns) @20kHz <120
Repetition frequency adjustment range (kHz) 20 - 60
Power regulating range (%) 10-100
The output optical fiber length (m) 2.0
Working temperature 0℃~ 45℃
Storage temperature -10℃~ 60℃
Humidity 30%~ 85%

Product Application:

Fire-proof material engraving
Stainless steel colorful marking
Alumina black marking
Insulation material marking
Deep carving
Laser welding
Laser cutting
