Working Principle for Fractional & Ultra Pulse Mode:

Fractional CO2 laser therapy works mainly on the principle of fractional heat damage. The fractional CO2 laser creates microscopic holes in the upper layer of skin and leaves the deeper part of the skin intact. The purpose of the treatment is to create controlled heat damage at the basal layer of skin leading to the reduction of wrinkles, pigmentation and acne scarring. The fractional CO2 laser also tightens and refines the skin as well as improving the long-term collagen and elastin reproduction.

Advantages:

1. Large LCD touch screen with human-computer interface.
2. 7-jointed articulated arm bring more convenient operating and save machine costs.
3. More than 20 kinds of scanning patterns to meet different patients’ requirement.
4. Continuous, super pulse, fractional Operation Modes for a wider use in clinical applications.
5. Spot size and interval are adjustable during treatment.
6. The best and stable quality laser tubes.
7. Easy to plug in and plug out the handpieces.
8. Safety Protection with automatic alarm.

Features:

1. Safe treatment: Totally safe and tested by hundreds of women in the world. The ideal laser wavelength is absorbed by the mucous membrane micron, to avoid any thermal damage by deep tissue or organ.
2. Fast treatment: Each treatment not more than 30 minute and 1 to 3 times treatment can completely solve the skin problems.
3. Effective treatment: Effective for all women who have the loosen vaginal, and effective prevention of gynecological inflammation.
4. Painless treatment: The patients only can feel warm/hot inside, does not feel any painful.
5. Air Turbo function: Bring smoke away rapidly when operation, protect both doctor and patient.

Specifications:

Laser type	CO2 RF Metal Sealed Laser Tube/ CO2 Glass Laser Tube
Wavelength	10,600nm
Power	40W (15w/30w/60w/80w optional)
Display	10.4" LCD Touch Screen
Aiming beam	650nm, ≤5mw
Light Delivery system	CO2 7 joints articulated arm
Operation mode	Ultra-pulse, Fractional (Dynamic Fractional, Curve Excision, Vaginal, Vulvae optional)
Fractional working mode	Interval continuous working
Scanning Graphics	straight line, square, rectangular, triangular, hexagonal, round, and oval
Scanning pattern size	0.1*0.1mm- 30*30mm
Scanning mode	Sequence mode, Mid split mode, Random mode
Spot size	0.1mm to 1.5mm
Pulse duration	0.1-20ms
Spot distance	0.1-2mm
Cooling system	Air cooling/ Water cooling (for CO2 glass tube)
Power supply	220V/110V±10%, 50HZ/60HZ

Applications:

1. Skin Resurfacing (Superficial Peeling)
2. Scar Removal: Acne scars, burnt scars and surgery scars, etc.
3. Removal: wart, neoplasms, pigment, body odor
4. Collagen Stimulation for skin tightening, lifting and whiten skin
5. Effective treatment with skin hydroponic, skin rough
6. Ablation and coagulation for the treatment of skin furrows and other textural irregularities.
7. Dermatological Surgery (including Striae Gravidarum)
8. Tighten vagina –Fast tightening, lasting constriction, tightness to improve 60%.
9. Clean the vagina – Deep anti-aging, young level to improve 80%.
10. Moist vagina – Improving secretion, moisture level to improve 80%.
11. Pink vagina – Vulva rejuvenation, lighten pigment and pinks labia parts, delicate degree to improve 70%
12. Sun damage recovery and skin renewing
13. Treat telangiectasis
14. Pierce ears
